MODEL CS7110/CS7210
CHILD
WITH INBUILT HARNESS
For a vehicle without a xed parcel shelf an extension strap(s) may be needed.
If so ring (02) 4728 8080 for nearest supply location. (Refer page 13)
Seat belt extenders should not be used if the seat belt is not long enough to secure the child
restraint.
IMPORTANT
!
UPPER ANCHORAGE STRAP ASSEMBLY
UPPER ANCHORAGE STRAP ADJUSTER
ATTACHMENT CLIP
ANCHOR FITTING + ATTACHMENT HARDWARE
SAFE GRIP RED BELT CLAMP (supplied in pocket)
VEHICLE SEAT BELT
“FORWARD-FACING SEAT BELT PATH” MARKER
(EACH SIDE OF RESTRAINT - COLOURED YELLOW)
COMFORT COVER
A - SEAT BASE
B - BACKREST
SHOULDER HEIGHT MARKER
HARNESS SHOULDER STRAPS
BUCKLE ASSEMBLY
HARNESS ADJUSTER
HARNESS ADJUSTMENT STRAP
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14. SHOULDER PADS
15. BUCKLE PAD
16. PILLOW (if applicable)
17. PADDED INSERT (if applicable)
5
16
10
14
8 A
8 B
15
7
13
12
11
17
6
9
8
