CS7110/CS7210
BOOSTER
WITH LAP-SASH SEAT BELT
1
2
3
4
For a vehicle without a xed parcel shelf an extension strap(s) may be needed.
If so ring (02) 4728 8080 for nearest supply location. (Refer page 13)
Seat belt extenders should not be used if the seat belt is not long enough to secure the child
restraint.
IMPORTANT
!
5
16
10
14
8 A
8 B
15
7
7
13
12
11
17
6
9
UPPER ANCHORAGE STRAP ASSEMBLY
UPPER ANCHORAGE STRAP ADJUSTER
ATTACHMENT CLIP
ANCHOR FITTING + ATTACHMENT HARDWARE
SAFE GRIP RED BELT CLAMP (SUPPLIED IN POCKET)
VEHICLE SEAT BELT
“BOOSTER SEAT BELT PATH” MARKER
(EACH SIDE OF RESTRAINT - COLOURED RED)
COMFORT COVER
A - SEAT BASE
B - BACKREST
SHOULDER HEIGHT MARKER
1.
2.
3.
4.
5.
6.
7.
8.
9.
