BOOSTER
WITH LAP-SASH SEAT BELT
USING LAP-SASH SEAT BELT
Pass the shoulder belt through the belt sash guide
(refer Figure 3) which is fastened to the restraint by a
webbing strap. Adjust the position so that the
shoulder belt lies comfortably over the child’s
shoulder (Refer Figure 4). Adjust to the required
length.
Figure 3
SASH
GUIDE
WEBBING
STRAP
SASH
WEBBING
OF SEAT
SELT
SASH GUIDE
SAFETY WARNING
A sash belt under the
arm or behind the back
is dangerous
WARNING
!
OR
Always use this sash guide
IMPORTANT
!
DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR.
Fit the seat belt rmly to the child.
A LOOSE RESTRAINT OR HARNESS IS DANGEROUS.
WARNING
!
SASH
GUIDE
B
A
