ACCESSORIES
SHOULDER PADS (if tted)
The shoulder pad is designed to add extra
comfort for baby or child.
STANDARD
Separate press-studs and remove the
shoulder pads from harness
To attach shoulder pads, ensure press studs
face away from the child and re-attach.
Step 1:
Step 2:
SPREADER
PLATE
DELUXE
Turn the restraint so that the back of the seat
is facing you.
Remove each shoulder harness through
the “G” connecting plate(refer Figure
1 & 2).
Pull the shoulder harness straps through the
shoulder slot holes in the seat body and
cover. They are now loose in the front of the
seat (refer Figure 2).
To attach shoulder pads, slide the shoulder
pad over the harness straps (refer Figure 3).
Rethread harness straps as per Steps 1 to 3
above.
The child restraint with shoulder pads is
ready to use.
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Figure 2
Figure 1
STANDARD
DELUXE
PULL
Figure 3
