COMPONENTS
Ref.
Qty.
Product Components
1
1
Hood Body, complete with: Controls, Light,
Blower, Filter.
2.1
1
Lower Decorative Chimney ( optional )
2.2
1
Upper Decorative Chimney ( optional )
3
1
Flange ( optional )
4
1
Exhaust Pipe
5
2
The Activated Charcoal filter ( optional )
Ref.
Qty
.
Installation Components
10
7
Screws 5 x 50
11
7
Wall Plugs
12
6
Screws 4.2X9.5
20
1
Hood fixing bracket ( optional )
21
2
Chimney fixing bracket ( 0 / 1 optional )
Qty.
Documentation
1
Instruction Manual
1
2.1
2.2
12
21
11
11
10
10
21
20
3
4
12
5
11
12
10
20
21
