RES-00-01239 RESISTOR
MOR-S 1WJ
2.2K OHM R285,385 2
RES-00-01112 RESISTOR
MOR-S 2WJ
2.2 OHM R253 1
RES-00-01067 RESISTOR
MOR-S 2WJ
10 OHM R71,81 2
RES-00-01222 RESISTOR
MOR-S 2WJ
47 OHM R242,342 2
RES-00-00844 RESISTOR
MOR-S 2WJ
100 OHM R77 1
RES-00-01078 RESISTOR
MOR-S 2WJ
1K OHM R250,251 2
RES-00-00853 RESISTOR
MOR-S 2WJ
2.2K OHM R209,210,252,309,310,401 6
RES-00-01099 RESISTOR
MOR-S 2WJ
3.9K OHM R76,86 2
RES-00-00947 RESISTOR SHUNT RESISTOR 5WJ 0.01 OHM R240,340 2
REN-00-00001 RESONATOR
2.56MHz ZTA2.56MG
X501 1
ELC-00-00357 CAPACITOR ELECTROLYTIC"BP" 10uF/100V C221 1
ELC-00-00009 CAPACITOR ELECTROLYTIC"BP" 33/100V C215 1
ELC-00-00232 CAPACITOR ELECTROLYTIC"SMS" 220/50V C402 1
ELC-00-00726 CAPACITOR ELECTROLYTIC"WL" 1000/35V C51,52,53,54,55,56 6
ELC-00-00187 CAPACITOR ELECTROLYTIC "SHL" 2200uF/50V C76,77,86,87,208,210 6
MYC-00-00076 CAPACITOR
MYLAR 10% 100V "BOX TYPE"
225K C70,78,80,88,212,223,312,820 8
COI-00-00096 INDUCTOR BAR COIL CL-320 L1 1
COI-00-00093 INDUCTOR BAR COIL CL-510 L6,7 2
COI-00-00073 INDUCTOR DRUM COIL CL-2200 L3 1
COI-00-00070 INDUCTOR DRUM COIL CL-1900C L4 1
GAP-00-029A0 GAP PAD 25x50x5t L4 1
COR-TF-00409 CORE 44 PHI MAG T1 , 44PHI 4T(0.7X18):10T(0.7X4):4T(0.7X1) 1
POWER
3P TERMINAL DST0010-00 TER1 1
SPEAKER
4P TERMINAL TM0009-01 TER2 1
HOD-00-00006 FUSE HOLDER PCB TYPE JSF08031P FUSE1,2 2
FUS-AT-00006 AUTO FUSE AUTO FUSE 30A SET(2)+ACCESSORY(2) 4
JAC-00-00043 RCA JACK GOLD PLATE(TOP RED) DJB-554A RCA101 1
CON-00-00002 WAFER LWL0640-02P CLIP 1
CON-00-00033 WAFER LWL0640-03P 1ST POWER,2ND POWER 2
JUP-00-00003 JUMPER BAR JUMPER 35m/m BJ3 1
JUP-00-00005 JUMPER BAR JUMPER 55 m/m BJ4 1
JAC-00-00050 MODULAR JAC
K 4P,BLACK DEK623PCB4-B MOD1 1
REL-10-00030 RELAY DC 40A 12V NT90NAS-DC12VCB0.9REL1 1
THS-00-00013 THERMISTOR FTD5-350 50K TH1 1
VOL-00-00134 SEMI VOLUME 6PHI , 5KB(straight TYPE) RG06P-5KB VR501 1
VOL-00-00335 VOLUME V12L5(9X5)G(PH2D)N15S
15B20K x 2
VR101 1
VOL-00-00336 VOLUME V12L5(9X5)G(PH2D)N15S 15C50K x 2 VR102 1
VOL-00-00352 VOLUME
V12L5(9X5) G(PH2D)N 15S
B500 x 2 VR103 1
VOL-00-00353 VOLUME
V12L5(9X5) G(4R)(PH2D)N 15S
A2Kx2+A200Kx2 VR104 1
TUB-00-00008 TEFLON TUBE 0.7 PHI 10 m/m TH1 2
ICO-00-00021 I.C SMD PWM TL494C U1 1
ICO-00-00094 I.C SMD "FLP-8" KIA393F U2,3 2
TRS-00-00098 TRANSISTOR SMALL SIGNAL PNP,SOT-23 KTA1504GR Q3,4,5 3
TRS-00-00113 TRANSISTOR SMALL SIGNAL NPN,SOT-23 KTC3875GR Q2,6 2
DIO-00-00117 DIODE SWITCHING SIGNAL RLS4148/LL4148 D3,4,5,6 4
Electrical Parts List cont'd
