RES-12-00243 RESISTOR SMD "0805"1/10WF 8.2K OHM R6 1
RES-08-00035 RESISTOR SMD "0805"1/10WF 20K OHM R32 1
RES-08-00048 RESISTOR SMD "0805"1/10WF 27K OHM R33 1
RES-08-00245 RESISTOR SMD "0805"1/10WF 51K OHM R29 1
RES-08-00100 RESISTOR SMD "0805"1/10WF 56K OHM R5 1
RES-08-00249 RESISTOR SMD "0805"1/10WF 110K OHM R28 1
RES-08-00250 RESISTOR SMD "0805"1/10WF 430K OHM R4 1
RES-08-00193 RESISTOR SMD "0805"1/10WJ 4.7 OHM R11 1
RES-08-00163 RESISTOR SMD "0805"1/10WJ 220 OHM R30 1
RES-08-00148 RESISTOR SMD "0805"1/10WJ 1K OHM R16,38,39 3
RES-08-00129 RESISTOR SMD "0805"1/10WJ 1.8K OHM R2 1
RES-08-00151 RESISTOR SMD "0805"1/10WJ 2.2K OHM R9,10 2
RES-08-00156 RESISTOR SMD "0805"1/10WJ 2.7K OHM R3 1
RES-08-00191 RESISTOR SMD "0805"1/10WJ 4.7K OHM R7,8,24,25,27 5
RES-08-00201 RESISTOR SMD "0805"1/10WJ 5.6K OHM R17,18,19 3
RES-08-00132 RESISTOR SMD "0805"1/10WJ 10K OHM R34 1
RES-08-00164 RESISTOR SMD "0805"1/10WJ 22K OHM R12,14,15,22,26 5
RES-08-00170 RESISTOR SMD "0805"1/10WJ 27K OHM R13 1
RES-08-00130 RESISTOR SMD "0805"1/10WJ 100K OHM R20 1
RES-08-00149 RESISTOR SMD "0805"1/10WJ 1M OHM R21,23,31,35 4
RES-12-00189 RESISTOR SMD "1206"1/8WJ 4.7 OHM R1 1
CEC-08-00002 CAPACITOR CHIP"0805" 50V 5% 102P C8 1
CEC-08-00040 CAPACITOR CHIP"0805" 50V 5% 473P C5 1
CEC-08-00004 CAPACITOR CHIP"0805" 50V 5% 104P C18,19,20,22 4
TRS-00-00087 TRANSISTOR SMALL SIGNAL PNP KTA1023Y Q1 1
TRS-00-00090 TRANSISTOR SMALL SIGNAL PNP KTA1266GR Q7,8 2
RES-00-00038 RESISTOR METAL FILM 1/2WJ 220 OHM R36,37 2
ELC-00-00229 CAPACITOR ELECTROLYTIC"SMS" 4.7uF/50V C4,9,11,17,23 5
ELC-00-00197 CAPACITOR ELECTROLYTIC"SMS" 22uF/16V C15,16 2
ELC-00-00199 CAPACITOR ELECTROLYTIC"SMS" 100uF/16V C10,12 2
MYC-00-00020 CAPACITOR MYLAR 5% 100V 102J C13 1
HED-00-00100 HEADER PIN PIN HEADER C-TYPE 6P TM2007-C9G-06P HP1 1
HED-00-00228 HEADER PIN PIN HEADER C-TYPE 8P TM2007-C9G-08P HP2 1
ICO-00-00095
I.C COMPARATOR DIP-8P KIA393P U90 1
RES-00-00437
RESISTOR METAL FILM 1/5WF 1K OHM R97
RES-00-00402
RESISTOR METAL FILM 1/5WF 10K OHM R95
RES-00-00550
RESISTOR METAL FILM 1/5WF 51K OHM R96
RES-00-00556
RESISTOR METAL FILM 1/5WF 56K OHM R94
RES-00-00573
RESISTOR METAL FILM 1/5WF 68K OHM R93
RES-00-00635
RESISTOR CARBON FILM 1/5WJ 1M OHM R98
RES-00-00029
RESISTOR METAL FILM 1/2WJ 1K OHM R192,292
CEC-00-00005
CAPACITOR CERAMIC TUBULAR 50V 103P C91,92,93
CEC-00-00006
CAPACITOR CERAMIC TUBULAR 50V 104P C90
DIO-00-00321
LED BLUE 3PHI MS-L330CBHSK LED1,2,3 3
CON-00-00139
WAFER LAL0640-2P CLIP 1
CON-00-00140
WAFER LAL0640-3P 1ST POWER,2ND POWER 2
WIR-AS-00220
WIRE ASS'Y BK,RED CHL0640-2P(300m/m) CLIP 1
WIR-AS-00218
WIRE ASS'Y BK,RED,GREEN CHL0640-3P(300m/m) 1ST POWER 1
WIR-AS-00219
WIRE ASS'Y BK,YELLOW,GREEN CHL0640-3P(300m/m) 2ND POWER 1
Electrical Parts List cont'd
Power Amplifier Reference 610a/611a
