Reference 611a Electrical Parts List Addendum
The following chart below represents the only electrical parts
differences in 610a and 611a models:
MODEL PART NAME PART NUMBER SPEC DESIGNATOR
REF 610a RESISTOR RES-00-00586 1/5WF 820 OHM R116
1
REF 611a RESISTOR RES-00-00474 1/5WF 240 OHM R116
REF 610a RESISTOR RES-00-00482 1/5WF 2K OHM R117
2
REF 611a RESISTOR RES-00-00554 1/5WF 560 OHM R117
REF 610a POWER TERMINAL TER-00-00163 (3P) DST0010-00 TER1
3
REF 611a
POWER TERMINAL
TER-00-00278 (3P) DK-03B04-AG-5-UP TER1
REF 610a SPEAKER TERMINAL TER-00-00034 (4P) TM0009-01 TER2
4
REF 611a
SPEAKER TERMINAL
TER-00-00276 (4P) DK-04A04-AG-5-UP TER2
Reference 610a/611a
Power Amplifier
20
