Limiter (yes/no) yes
THD at Max. Output
Power
10 % functional
ck.
Maximum Output
Power
Maximum THD as a result of
limiting.
Features
Phase Switch (yes/no) YES — functional
ck.
45 deg additional phase
shift/switch op.OK
Volume pot Taper
(lin/log)
LOG — functional
ck.
Input Configuration —
Line In (L&R) LR — functional
ck..
Spkr/Hi Level In
(L&R) L,R — functional
ck..
Enabled w/Line/Spkr
Input Select Switch
Spkr Out: Hi Pass Filter 100 Hz functional
ck..
8 ohm Satellite: 6dB/oct passive xover 200 Uf cap. Non
polarized
Signal-Present LED Yes
Signal-Present Input
Freq.
35 Hz Nominal
Signal-Present Level line
in
30 mV 35Hz into Line
Input w/ 1 ch.
Driven
Zo=600 Ohms
Signal-Present Speaker
-in
2.6 V 35Hz into Speaker
Input w/ 1 ch.
Driven
Signal-Present Turn-on
time
1 sec. Amp connected and AC on, then input signal
applied
Auto Mute/ Turn-OFF
Time
> 3 min. T before muting,
after signal is
removed
Power on Delay time 1 sec. 3 AC Power Applied
Transients/Pops
Signal-Present Transient 5 mV-peak n/a @ Speaker Outputs
Turn-on Transient 1 mV-peak 2v-pp @ Speaker Outputs AC Line cycled from OFF to
ON
Turn-off Transient 2 mV-peak 4v-pp @ Speaker Outputs AC Line cycled from ON to
OFF
Efficiency
Stand-by Input Power 20 Watts 28 @ nom. line
voltage
Input Line voltage 120 VAC
Power Cons.@rated
power
210 Watts 220 @ nom. line
voltage
Efficiency 95.2
4%
% 54.55% Relative to rated
output
Protection
Short Circuit Protection YES functional
ck..
Direct short at
output
Thermal Protection YES functional
ck..
@1/8 max
unclipped Power
Power transformer 85 deg C.
Line Fuse Rating 2 Amps 2 Slo-Blo type
5
Amplifier/Subwoofer BU-150
