Amplifier/Subwoofer BU-150
CONTROLS AND THEIR FUNCTION
1. High-Level input and Output terminals
2. Low-Level Input Jacks: connect to preamplifier outputs
3. Low Pass: This is the crossover frequency control
which determines the upper-corner roll-off points.
4. Power-On indicator
5. Phase: 0/180 switch to change audio-signal polarity.
6. Level: This controls the volume level of the subwoofer.
