TSS-1100 120V ELECTRICAL PARTS LIST
Part Number Qt
y
Description Reference Designator
MAIN PCB
Resistors
020-000098-400 4 Carbon film resistor 0R 1/8W C22-C24,31
020-220497-120 1 Carbon film resistor 2K2 1/4W J R11
021-100401-120 1 MOF Resistor 1K 1W J Kink R103
021-220202-120 1 MOF Resistor 22R 2W(S) J MB R10
021-240405-020 4 MOF Resistor 2K4/5WS J 17x6 R6,9,R7A,R9A
022-500003-020 1 Resistor KNP 0R05 3WS J FK TYPE R104
024-100298-120 2 SMD Resistor 10R 1/8W J 0805 R81,82
024-100398-120 1 SMD Resistor 100R 1/8W J 0805 R62
024-100498-100 1 SMD Resistor 1K 1/8W F 0805 R110
024-100498-120 7 SMD Resistor 1K 1/8W J 0805 R79,83,92,95,96,105,65
024-100598-120 26 SMD Resistor 10K 1/8W J 0805
R2,17,19,37,54,58,63,71,72,74,75,84,88,89,97,106,113-
117,111,123,124, 119,120
024-100598-120 3 SMD Resistor 10K 1/8W J 0805 R2-4
024-100698-120 2 SMD Resistor 100K 1/8W J 0805 R3,112
024-100898-120 1 SMD Resistor 10M 1/8W J 0805 R121
024-110498-120 1 SMD Resistor 1K1 1/8W J 0805 R2A
024-110598-100 1 SMD Resistor 11K 1/8W F 0805 R98
024-110698-100 1 SMD Resistor 110K 1/8W F 0805 R4A
024-133598-100 1 SMD Resistor 13K3 1/8W F 0805 R35A
024-137698-100 1 SMD Resistor 137K 1/8W F 0805 R32
024-160398-120 1 SMD Resistor 160R 1/8W J 0805 R6A
024-162598-100 1 SMD Resistor 16K2 1/8W F 0805 R39
024-178498-100 1 SMD Resistor 1K78 1/8W F 0805 R38
024-180598-100 1 SMD Resistor 18K 1/8W F 0805 R29
024-187698-100 1 SMD Resistor 187K 1/8W F 0805 R45
024-200498-120 1 SMD Resistor 2K 1/8W J 0805 R108
024-200598-120 1 SMD Resistor 20K 1/8W J 0805 R94
024-220398-120 1 SMD Resistor 220R 1/8W J 0805 R90
024-220498-121 4 SMD Resistor 2K2 1/8W J 0805 R1,87,61,68
024-220598-120 1 SMD Resistor 22K 1/8W J 0805 R118
024-220798-120 1 SMD Resistor 2M2 1/8W J 0805 R80
024-237598-120 1 SMD Resistor 23K7 1/8W F 0805 R48
024-270498-120 2 SMD Resistor 2K7 1/8W J 0805 R73,64
024-280498-100 2 SMD Resistor 2K8 1/8W F 0805 R51,53
024-300398-120 1 SMD Resistor 300R 1/8W J 0805 R55
024-300598-120 1 SMD Resistor 30K 1/8W J 0805 R56
024-330498-120 8 SMD Resistor 3K3 1/8W J 0805 R7,8,12-15,59,67
024-330598-120 2 SMD Resistor 33K 1/8W J 0805 R4,5
024-332498-100 2 SMD Resistor 3K32 1/8W F 0805 R26,27
024-390498-120 1 SMD Resistor 3K9 1/8W J 0805 R93
024-390598-120 1 SMD Resistor 39K 1/8W J 0805 R77
024-430498-120 1 SMD Resistor 4K3 1/8W J 0805 R78
024-453498-100 1 SMD Resistor 4K53 1/8W F 0805 R36
024-453598-100 1 SMD Resistor 45K3 1/8W F 0805 R30
024-470298-120 2 SMD Resistor 47R 1/8W J 0805 R101,102
024-470398-120 3 SMD Resistor 470R 1/8W J 0805 R76,99,100
024-470498-120 2 SMD Resistor 4K7 1/8W J 0805 R85,86
024-470598-120 4 SMD Resistor 47K 1/8W J 0805 R44,47,49,107
024-470698-120 1 SMD Resistor 470K 1/8W J 0805 R70
024-470798-120 1 SMD Resistor 4M7 1/8W J 0805 R60
024-510398-120 1 SMD Resistor 510R 1/8W J 0805 R57
024-560498-120 1 SMD Resistor 5K6 1/8W J 0805 R1
024-560598-120 1 SMD Resistor 56K 1/8W J 0805 R122
024-620398-100 2 SMD Resistor 620R 1/8W F 0805 R16,18
024-680398-120 1 SMD Resistor 680R 1/8W J 0805 R5A
024-680498-120 6 SMD Resistor 6K8 1/8W J 0805 R46,91,40-43
024-680598-120 6 SMD Resistor 68K 1/8W J 0805 R33,34A,31,50,52,66
024-820598-120 1 SMD Resistor 82K 1/8W J 0805 R69
025-010300-000 1 Thermister TSE-103 K L:50mm TH1
