MAIN PCB
026-200595-269 1 VR PN:RD163121R03D-20KBx2(EJ) FREQUENC
Y
VR2
026-500495-252 1 VR 5KA PN:RK163111R52B-5KA (EJ) LEVEL VR1
Capacitors
031-100144-103A 1 SMD Capacitor 0u001/50V K 0805 X7R TAP C79
031-100184-100A 2 SMD Capacitor 0u01/250V K 0805 X7R TAP C3,7
031-100244-100A 7 SMD Ceramic capacitor 0u01/50V K 0805 X7R 66,67,5,10,33,45,51,
031-100343-100A 2 SMD Capacitor 100pF/50V J 0805 NPO TAP C36,58)
031-100344-100 4 SMD Capacitor 0u1/50V K 0805 X7R TAPIN C1-4
031-100344-100A 16 SMD Capacitor 0u1/50V K 0805 X7R TAPIN C11,42-44,46-49,52,54,55,60,63,71,74,77
031-220243-103 1 SMD Capacitor (PHYCOMP) 0u022/50V J 080 C40
031-220344-300A 3 SMD Capacitor 220pF/50V K 0805 NPO TAP C20,21,19
031-330444-300 1 SMD Capacitor 3300pF/50V K 0805 X7R TA C34
031-470244-102A 2 SMD Capacitor 0u047/50V K 0805 X7R TAP C62,59
031-470344-100A 1 SMD Capacitor 470pF/50V K 0805 X7R TAP C80
031-560243-100A 2 SMD Capacitor 56pF/50V J 0805 NPO TAPI C57,61
031-820343-101A 1 SMD Capacitor 820pF/50V J 0805 NPO TAP C56
032-100484-200 2 END Mylar capacitor 1uF/250V K P:15 C70,C70B
032-270393-300 1 Mylar capacitor (ESK) 0u27/63V J (R) P:5 C29
032-820244-200 1 Mylar capacitor 0u082/100V K (R) C30
033-470464-270 1 NPE Capacitor 1K 4u7/100V K1 C73
033-680464-270 1 NPE Capacitor 6u8/100V K10 C72
034-100525-300 1 Electrolytic capacitor 10uF/25V M (R)0511 P:5 C35
034-100625-300 1 Electrolytic capacitor 100uF/25V M (R)6 C64
034-220525-301 5 Electrolytic capacitor 22uF/25V M (R)5x11 P:5 C4,9,41,50,53
034-330515-000 1 Electrolytic capacitor 33uF/16V M (R)0511 P:5 C39
034-330525-300 1 Electrolytic capacitor 33uF/25V M (R)05 C1
034-330615-300 2 Electrolytic capacitor 330uF/16V M (R)0812 P:5 C12,78
034-330780-300 2 Electrolytic capacitor 85 SNAPIN 3300uF/80V C6,8
034-470415-301 1 Electrolytic capacitor 4u7/50V M (R)0511 P:5 T C2
034-470515-200 1 Electrolytic capacitor 47uF/16V M (R)0511 P:2. C37
034-470615-301 1 Electrolytic capacitor 470uF/16V M (R)0812 P:5 C65
035-100393-301 2 Mylar capacitor (ESK TYPE) 0u1/63 C28,2A
035-100443-300 2 Mylar capacitor (ESK TYPE) 1uF/63 C25,26
035-220393-300 1 PE Capacitor 0u22/63V J P:5 C27
035-470293-300 1 PE Capacitor 0u047/63V J P:5 C1A
038-100363-300 2 MPE capacitor P:5 0u1/100V J C68,69
039-100384-100 1 Safety capacitor (0u1/250V) PN:HQX0.1K27 CXAC1
Semiconductor
s
051-000600-100 2 Transistor NPN PN:MPSW06RLRA TO-92 T Q2,Q16
051-003100-000 1 Transistor NPN PN:TIP 31C TO-220 (MO Q4
051-005600-100 1 Transistor PNP PN:MPSW56RLRA TO-92 T Q3
051-222200-100 1 Transistor NPN (ON SEM) PN:MPS2222AR Q21
051-290700-100 2 Transistor PNP (ON) PN:MPS2907A RLRA Q19,23
051-540101-000 1 Transistor PNP(FAIRCHILD PN:2N5401 T Q1
051-555100-000 1 Transistor NPN PN:2N5551 TO-92 TAPIN Q17
051-640001-000 2 MOSFET N-Channel PN:IRF640N TO-2 Q18,22
052-400080-000 1 Bridge Rectifier PN:RS804 400V,8A BR1
053-211100-000 1 IC, IR2111 HALF-BRIDGE DRIVER U7
054-000100-100 5 SMD DIODE PN:ES1D 200V 1A D5,26,29,33,38
054-001002-100 1 SMD ZENER DIODE PN:BZX84C10 10V D35
054-001501-100 3 SMD ZENER DIODE PN:BZX84C15 15V D6,7,9
054-007200-100 2 SMD IC PN:TL072CDR SO-8 DUAL OP-AMP U1,5,6
054-007400-100 2 SMD IC PN:TL074CDR QUAD OP-AMP U2,3
054-008403-100 1 SMD ZENER DIODE BZX84C3V0 SOT-23 D25
054-011400-100 1 SMD Transistor PN:DTC114TKA SMT3 TAP Q7
054-033904-100 7 SMD Transistor PN:MMBT3904LT1 SOT23 Q11,14,13,5,8,25,9
054-033906-100 4 SMD Transistor PN:MMBT3906LT1 SOT23 Q6,10,12,15
054-045580-100 1 SMD IC NJM4558M-TE3 DUAL OP-AMP U4
054-050601-100 2 SMD ZENER DIODE PN:BZX84C5V6 5.6 D36,37
054-390402-100 1 SMD Transistor (SC00044) PN:MMBT3904TR Q1
054-414803-100 21 SMD DIODE PN:LL4148
D1-4,8,27,30,31,34,39, 11,14,16,17, 20-22,18,19,28,32
054-414803-100 2 SMD DIODE PN:LL4148 D1,2
