Infinity TSS-1100 - TSS-1100 120 V Electrical Parts List

MAIN PCB
054-540100-100 3 SMD Transistor (PNP) PN:MMBT5401 LT1 Q20,24,26
THERMAL SENSE PCB
024-100598-120 3 SMD Resistor 10K 1/8W J 0805 R138-R141
024-560498-120 1 SMD Resistor 5K6 1/8W J 0805 R140
031-100344-100 4 0U1/50V K 0805 X7R C81-82, C13,C38
054-007200-100 1 SMD IC TL072CDR SO-8 U8
054-390402-100 1 SMD Transistor MMBT3904TR Fairchild Q27
054-414803-100 2 SMD Diode LL4148 Vishay D44-45
Miscellaneous
1100-LED 1 LED ass'
y
042-010147-000 1 Transformer PN:YT-15250 (TSS1100/120V
043-300101-000 1 INDUCTOR PN:YT-10033 30uH L2
043-324300-000 1 INDUCTOR 324uH YT-10778 L4
043-560200-000 1 INDUCTOR 56uH YT-10779 L1
043-840100-000 1 Inductor PN:YT-14389 84uH TSS1100/23 L3
044-100100-000 2 SMD FERRITE BEAD PN:321611 600R/ FB1,FB2
061-020000-000 2 Knob ABS HTS-10/20 φ20x15m/m UL 94V-0 BLK
061-314002-000 2 Strain Relief P/N SB4F-2
061-400014-000 4 RUBBER FOOT ID:6.2 OD:11.5 t=2mm 55degree BLK
061-700044-000 3 Mica 13x18mm TO-220 holeless Q4,18,22
063-010012-000 4 Bracket for power transistor P/N:TRK-1 for ICx4
063-321102-000 1 PANEL (ARMANDO) 322x105.7x15mm A BS-94VO BL
K
063-531808-000 1 Bucket (PB-10/12) ABS 322x105.7x14 6.5mm BLK (94VO)
066-120300-900 5 CABLE TIE CV-120S
072-010007-000 1 RCA base SCJ-1020 2P(G) WHT,RED CONN1
073-011001-400 2 BRACKET 16x34mm t=0.8mm brass plated for PANEL
073-032315-601 1 Heatsink, black anodized 70x58x20mm, thread
073-050001-000 2 FUSE CLIP P/N:CFFH1206
074-020018-000 1 ROCKER SW (POWER) PN:RF1003-BB4-0
074-030002-000 2 TOGGLE SW PN:L101-T2B4QE SW5,SW6
074-300018-000 1 RELAY PN:943-1C-48D K1
083-041802-009 1 UL Power Cord SPT-2 BLK 6 feet
093-105202-300 1 FUSE:UL GSL(2AG) FUSE:2A,250V,5* F1
008-061215-000 1 GASKET C4305 12x15 t=5mm CR PSA for Thermister
008-062002-002 1 GASKET (PB10/12) PN:L-32 200x20m
008-062002-012 1 GASKET (PB10/12) 200x20mm t=2mm CR4305 PSA for Cover
008-062004-012 1 GASKET 200x35x3mm PSA for spkr cable
008-063208-000 6 GASKET C4305 321x8 t=1mm CR PSA for Cover
008-069304-000 6 GASKET C4305 93x4 t=1mm CR {SA for Cover
041-115001-000 1 BEAD COIL YT-10911 L5
230V VARIATIO
N
086-021818-030 1 VDE Power Cord LF2-75
093-205201-320 1 Fuse 1.25A/250V VBS UTE F1
042-010148-000 1 Power Transformer PT1
072-060170-000 4 Binding Post
072-060213-000 4 Binding Post Plug (Black)
072-060214-000 4 Binding Post Plug (Red)
TSS-1100
13
