Note that no color coding standards exist for DC power connections. The color coding used by the external DC power source at your site
determines the color coding for the leads on the power cables that attach to the terminal studs on each DC power supply.
Table 4 -48V DC Power Connector
Cable Pin Cable Color Description
1 Black Positive Return
2 Red Negative Input Voltage
3 Green/Yellow Safety Ground
Fan FRU ( ) SKU (Stock Keeping Unit)Field-Replaceable Unit
The Infoblox 1405 Series appliances ship with inbuilt fans that can be replaced. The following table lists the fans supported on an Infoblox 1405
series appliance:
SKU Description
T-PSU600-AC
FRU, Trinzic 1405, 2205, and 4005 Series AC Power Supply Unit, 600W
T-PSU600-DC
FRU, Trinzic 1405, 2205, and 4005 Series DC Power Supply Unit, 600W
Installing the Infoblox 1405 Series Appliance
Refer to the sections below to rack mount appliances in the Infoblox 1405 Series appliance, connect them to a power source, and cable them to a
network. Before proceeding, review the and follow the necessary precautions.Infoblox Safety Guide
Note: Ensure that you install the appliance in an environment that allows open air to the front and back of the appliance. Do not obstruct the
appliance or block air flow going from the front to the back of the appliance.
Rack Mounting Procedures
The Infoblox 1405 Series appliances mount into a standard 19" (48 cm) equipment rack. The appliances ship with accessory kits that contain the
following: a pair of rack slide brackets and chassis slide rails, a pair of rack ears, eight (8) 10-32 screws, and eight (8) 8-32 screws. To mount the
appliances to an equipment rack, you also need a #2 screwdriver with a cross-headed tip. Infoblox also offers an adjustable rail four-post rack
mounting kits that you can order separately. There are three ways to rack mount Infoblox 1405 Series appliances:
Two-post rack mount, as described in . Two-Post Rack Mount
Four-post rack mount, as described in .Four-Post Rack Mounting
Adjustable rail four-post rack mount, as described in .Adjustable Rail Four-Post Rack Mounting
Rack Mounting Safety Requirements
The following space and airflow requirements are required for Infoblox 1405 Series system operation:
Minimum clearance of 63.5 cm (25 in) in front of the rack
Minimum clearance of 76.2cm (30 in) in the rear of the rack
Minimum clearance of 121.9 cm (48 in) from the back of the rack to the back of another rack or row of racks
The Infoblox appliance draws air in through the front of the chassis and expels air through the rear. Adequate ventilation is required to allow
ambient room air to enter the system chassis and to be expelled from the rear of the chassis.
Two-Post Rack Mount
To mount the appliance to an equipment rack and secure it at the rear rack posts:
Align the mounting holes on the rack ears with the rear-most mounting holes on each side of the chassis.
Attach each rack ear on each side of the chassis with two (2) 8-32 screws, as shown in (left-side rack ear shown). For two-postFigure 6
rack mounting, the ears are placed to fix the center of the appliance at the point where the rack ears fasten to the two-post rack,
preventing strain on the chassis and maintaining a center of gravity.
To Next Page
