InFocus IN112 User Guide

11
Shutting down the projector
Auto Off Time
The projector also has an Auto Off Time feature that automatically turns the
projector off after no active sources are detected and no user interaction with the
projector is performed for 30 minutes. By default, this feature is off. You can
change the length of time, see page 29.
Turning off the projector
To turn the projector off, press the Power button on the remote or keypad. The
lamp turns off and the Power LED blinks blue for 1 minute while the fans continue
to run to cool the lamp. If the Power Saving Mode feature is on and when the lamp
has cooled, the LED lights blue and the fans stop. If the Power Saving Mode feature
is off and when the lamp has cooled, the LED blinks blue and the fans stop. Unplug
the power cable to completely power off the projector.
Troubleshooting your setup
If your image appears correctly on the screen, skip to the next section. If it does
not, troubleshoot the setup.
The Status Indicator Panel on top of the projector indicates the state of the
pro
jector and can help you troubleshoot
TEMP/LAMP
POWER
.
Table 3: Status indicator light behavior and meaning
Status Indicator Light Meaning
POWER: Solid blue
POWER: Blinking blue
1. If the Power Saving Mode feature is on,
the projector is plugged in.
2. The projector is on and initialized.
3. The projector is in normal operation.
1. If the Power Saving Mode is off, the
p
rojector is plugged in.
2. The projector is powering down and
th
e fans are cooling the projector.
POWER: Blinking blue
TEMP/LAMP: Blinking pink
POWER: Solid blue
TEMP/LAMP: Blinking pink
The projector fan(s) are not operating
co
rrectly and the projector has been shut
down.
The lamp failed to ignite.
Contact Technical Support if the problem
p
ersists. Visit www.infocus.com/support
to contact service.
POWER: Solid blue
TEMP/LAMP: Blinking red
The lamp has reached its end of life and
must be replac
ed. The lamp will continue
to operate untils it fails.
Contact Technical Support. Repair may be
nee
ded.
POWER: Solid blue
TEMP/LAMP: Blinking blue
1. The projector is overheating and the
lamp will be shut
off. The fans will
continue to run.
2. The projector will not turn back on
unt
il the cooling process is complete.

InFocus IN112 Specifications

General

Matrix size	0.55 \
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	1.5 - 11.9 m
Projection technology	DLP
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	4000:1
Screen size compatibility	40 - 303 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	100 kHz
Horizontal synchronization (min)	31 kHz
Projector brightness (economic mode)	2200 ANSI lumens
Focus	Manual
Offset	15 %
Throw ratio	1.97 - 2.17:1
Zoom capability	Yes
Focal length range	- mm
Lamp type	UHP
Lamp power	180 W
Light source type	Lamp
Lamp power (economic mode)	150 W
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
DVI port	No
Audio (L/R) in	-
USB connector type	Mini-USB B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
RMS rated power	2 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	260 W
Power consumption (standby)	1 W
Power consumption (typical)	235 W
Noise level	30 dB
Preset modes	Beige wall, Blackboard, Bright, Cinema, Custom, Presentation, Whiteboard
Certification	UL, c-UL, FCC, CE
Password protection type	User
Noise level (economic mode)	28 dB
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Operating altitude	0 - 3048 m
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, VGA

Weight and Dimensions

Depth	235 mm
Width	284 mm
Height	70 mm
Weight	2170 g
Package width	330 mm
Package height	150 mm
Package weight	3670 g
