InFocus IN112 User Guide

Setup
Status/Service
Basic Menu
3D Control...
Color...
PC...
Video...
( Advanced Menu )
MDL: IN112
FW: 0.13
Advanced Menu
27
Setup:
Audio Setup...
Internal Speaker:
turns the internal speaker on or off.
Closed Captioning...
Closed Captions: controls closed captioning. If the source is NTSC and
contains captions on the selected channel, then the projector will display
caption text overlaid on the image. When Closed Captions is off and volume
is muted, closed captioning will appear. Options are: Off, CC1 and CC2.
Image Setup...
Digital Zoom: reduces the size of projector’s display area. If the display area
has been resized by this setting, it can be moved by changing the Horz Shift
and Vert Shift settings.
Magnify Level:
magnifies the image. If the image has been magnifiedby this set-
ting, it can be moved by changing the Hor
z Shift and Vert Shift settings.
Rear Project: reverses the
image so you can project from behind a translu-
cent screen.
Ceiling Mount:
turns the image upside down for ceiling-mounted projection.
Keypad/Remote Settings...
Blank Key: s
elect what to display when the blank key on the remote is
pressed: your custom snapshot, a solid color screen (blue, black or white), or
the factory logo screen.
Custom Key: all
ows you to assign a different function to the Custom button,
allowing you to quickly and easily use the effect. Highlight an effect and press
^ or v on the keypad or Select on remote to choose a different one.
• Blank Screen: displays an empty screen.
•
Mute: turns off all sound.
•
Source: brings up a menu of available sources.
•
Auto Image: resets the projector to the source.
•
Freeze Screen: pauses the projected image.
•
Source Info: the default action. Shows the Source Info menu.
•
Projector Info: shows the Projector Info menu.
•
Overscan: removes noise around the image.
• AV Mute: enables or disables AV Mute function.
• Closed Captions: enables or disables Closed Captions.
Keypad: enables or locks the projector keypad.

InFocus IN112 Specifications

General

Matrix size	0.55 \
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	1.5 - 11.9 m
Projection technology	DLP
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	4000:1
Screen size compatibility	40 - 303 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	100 kHz
Horizontal synchronization (min)	31 kHz
Projector brightness (economic mode)	2200 ANSI lumens
Focus	Manual
Offset	15 %
Throw ratio	1.97 - 2.17:1
Zoom capability	Yes
Focal length range	- mm
Lamp type	UHP
Lamp power	180 W
Light source type	Lamp
Lamp power (economic mode)	150 W
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
DVI port	No
Audio (L/R) in	-
USB connector type	Mini-USB B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
RMS rated power	2 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	260 W
Power consumption (standby)	1 W
Power consumption (typical)	235 W
Noise level	30 dB
Preset modes	Beige wall, Blackboard, Bright, Cinema, Custom, Presentation, Whiteboard
Certification	UL, c-UL, FCC, CE
Password protection type	User
Noise level (economic mode)	28 dB
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Operating altitude	0 - 3048 m
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, VGA

Weight and Dimensions

Depth	235 mm
Width	284 mm
Height	70 mm
Weight	2170 g
Package width	330 mm
Package height	150 mm
Package weight	3670 g
