InFocus IN3134a - Views of Projector Parts; Front-Right View

— 2 —
Views of Projector Parts
Front-right View
ITEM
LABEL
DESCRIPTION
SEE PAGE
1.
IR receiver
Receive IR signal from remote control.
2.
Lens
Projection Lens.
3.
Focus ring
Focuses the projected image.
15
4.
Zoom ring
Enlarges the projected image.
5.
Function keys
See Top view—On-screen Display (OSD) buttons
and LEDs.
3
Important:
Do not block ventilation openings. Locate the projector in a well-ventilated area without obstructions
to intake or exhaust vents. Do not place the projector on a tablecloth or other soft covering that may
block the vents. Ventilation openings on the projector allow for good air circulation.
1 23 4 5
