InFocus LP 120 User Manual

8
First-time projector use with Windows 98
The first time you connect a computer running Windows 98 to the projector,
the computer recognizes the projector as “new hardware” and the Add
New Hardware Wizard appears. Follow these instructions to use the Wiz-
ard to load the correct driver (which was installed with your Windows
operating system).
If you are running Windows 2000, Windows ME, or Windows XP, skip these
steps and go to “Adjusting the image” on page 10.
a Click Next to begin searching for the driver.
b Make sure “Search for the best driver” is selected, then click Next.
c Uncheck any checked boxes, then click Next. Windows automatically
locates the driver. If this driver has been removed, reload the driver using
your Windows operating system CD.
d When Windows finds the driver, you are ready to install it. Click Next.
a
b
c
d

InFocus LP 120 Specifications

Display

native resolution	1024 x 768
display technology	DLP 0.7" XGA 12° DMD DDR
brightness	1000 max ANSI lumens

Projection Specifications

contrast ratio	2000:1 full on/full off
projection lens	Zoom lens with manual focus and manual zoom adjust
throw ratio	1.8 – 2.1:1 (typical)
minimum projection distance	1.5 m
maximum projection distance	5.0 m
image size (diagonal)	0.9 m to greater than 3.5 m

Power and Consumption

power consumption	150 watts
power supply	100V – 240V at 50 – 60 Hz
lamp	120W UHP / 2000 (typical)
lamp warranty	90 days or 500 hours, whichever comes first

Operating Environment

operating temperature	5° – 40° C at sea level
operating temperature imperial	41° – 104° F
audible noise	36dB

Weight and Dimensions

dimensions	2.05" (H) x 3.69" (L) x 9.75" (W)
dimensions metric	5.21 cm (H) x 9.37 cm (L) x 24.77 cm (W)
weight	0.9 kg
