InFocus LP 120 User Manual

6
Connecting a computer
Required computer connections
Connect the black end of the computer cable to the Computer in connector
on the projector. Connect the blue end to the video (VGA) port on your com-
puter. If you are using a desktop computer with a single VGA port, you first
need to disconnect the monitor from that computer’s video port.
Connect the black power cable to the connector on the side of the projector
and to your electrical outlet.
The Power LED on the projector’s keypad turns solid green and the fans
start to run.
NOTE: Always use the power cable that shipped with the projector.
Optional computer connections
To advance slides in a PowerPoint™ presentation using the remote, plug the
USB connector on the computer cable into the USB mouse connector on
your computer. USB drivers must be installed to use the USB feature. For
more information, see page 9.
To have sound with your presentation, connect the audio cable to your com-
puter and to the computer Audio In connector on the projector.
connect computer cable
connect power cable
connect USB portion of
computer cable
connect audio cable

InFocus LP 120 Specifications

Display

native resolution	1024 x 768
display technology	DLP 0.7" XGA 12° DMD DDR
brightness	1000 max ANSI lumens

Projection Specifications

contrast ratio	2000:1 full on/full off
projection lens	Zoom lens with manual focus and manual zoom adjust
throw ratio	1.8 – 2.1:1 (typical)
minimum projection distance	1.5 m
maximum projection distance	5.0 m
image size (diagonal)	0.9 m to greater than 3.5 m

Power and Consumption

power consumption	150 watts
power supply	100V – 240V at 50 – 60 Hz
lamp	120W UHP / 2000 (typical)
lamp warranty	90 days or 500 hours, whichever comes first

Operating Environment

operating temperature	5° – 40° C at sea level
operating temperature imperial	41° – 104° F
audible noise	36dB

Weight and Dimensions

dimensions	2.05" (H) x 3.69" (L) x 9.75" (W)
dimensions metric	5.21 cm (H) x 9.37 cm (L) x 24.77 cm (W)
weight	0.9 kg
