InFocus LP 120 User Manual

7
Displaying a computer image
Remove the lens cap.
Press the Power button on the top of the projector.
The LED flashes green and the Interactive Display illuminates and counts
down the time to image display. When the lamp comes on, the startup
screen is displayed and the LED is steady green. It can take a minute for the
image to achieve full brightness.
? No startup screen? Get help on page 15.
Turn on your computer.
The computer’s image should appear on the projection screen. If it doesn’t,
press the Source button on the projector’s keypad.
Make sure your laptop’s external video port is active.
Many laptops do not automatically turn on their external video port when a
projector is connected. Refer to your computer’s documentation to learn the
activation commands specific for your computer. For example, some lap-
tops use a key combination of FN + F5 to turn the external display on and
off.
? No computer image? Try pressing the Auto Image
button on the keypad. Get help on page 16.
remove lens cap
press Power
turn on computer
source
activate laptop’s external port

InFocus LP 120 Specifications

Display

native resolution	1024 x 768
display technology	DLP 0.7" XGA 12° DMD DDR
brightness	1000 max ANSI lumens

Projection Specifications

contrast ratio	2000:1 full on/full off
projection lens	Zoom lens with manual focus and manual zoom adjust
throw ratio	1.8 – 2.1:1 (typical)
minimum projection distance	1.5 m
maximum projection distance	5.0 m
image size (diagonal)	0.9 m to greater than 3.5 m

Power and Consumption

power consumption	150 watts
power supply	100V – 240V at 50 – 60 Hz
lamp	120W UHP / 2000 (typical)
lamp warranty	90 days or 500 hours, whichever comes first

Operating Environment

operating temperature	5° – 40° C at sea level
operating temperature imperial	41° – 104° F
audible noise	36dB

Weight and Dimensions

dimensions	2.05" (H) x 3.69" (L) x 9.75" (W)
dimensions metric	5.21 cm (H) x 9.37 cm (L) x 24.77 cm (W)
weight	0.9 kg
