InFocus Quantum Laser Core Series - Page 20

4.3.2 XGA SERIES - 1.3X ZOOM LENS
Screen Size Projection Distance (PD)
Inches Meters Inches Meters Feet Offset (OFS)
Diagonal
(D)
Width
(W)
Height
(H)
Width
(W)
Height
(H)
Wide Tele Wide Tele Meters Inches
29.2 0.63 0.39 24.76 15.48 - 1.0 - 3.28 0.04 1.57
40 0.86 0.54 33.92 21.2 1.0 1.4 3.28 4.59 0.05
1.97
50 1.08 0.67 42.40 26.5 1.3 1.7 4.27 5.58 0.07 2.76
60 1.29 0.81 50.88 31.8 1.6 2.1 5.25 6.89 0.08 3.15
70 1.51 0.94 59.36 37.1 1.8 2.4 5.91 7.87 0.10 3.94
80 1.72 1.08 67.84 42.4 2.1 2.7 6.89 8.86 0.10 3.94
90 1.94 1.21 76.32 47.7 2.3 3.1 7.55 10.17 0.12 4.72
100 2.15 1.35 84.80 53 2.6 3.4 8.53 11.15 0.13 5.12
120 2.58 1.62 101.76 63.6 3.1 4.1 10.17 13.45 0.16 6.30
150 3.23 2.02 127.20 79.5 3.9 5.1 12.80 16.73 0.20 7.87
180 3.88 2.42 152.64 95.4 4.7 6.2 15.42 20.34 0.25 9.84
200 4.31 2.69 169.60 106 5.2 6.8 17.06 22.31 0.27 10.63
250 5.38 3.37 212.00 132.5 6.5 8.6 21.33 28.22 0.33 12.99
300 6.46 4.04 254.40 159 7.8 - 25.59 - 0.40 15.75
383.7 8.26 5.17 325.38 203.4 10.0 - 32.81 - 0.51 20.08
