3D
HDMI 3D Input Input Timing
With 3D InfoFrame information
1280 X 720P @ 50Hz Top - and - Bottom
1280 X 720P @ 60Hz Top - and - Bottom
1280 X 720P @ 50Hz Frame packing
1280 X 720P @ 60Hz Frame packing
1920 X 1080i @50 Hz Side- by-Side (Half)
1920 X 1080i @60 Hz Side- by-Side (Half)
1920 X 1080P @24 Hz Top - and – Bottom
1920 X 1080P @24 Hz Frame packing
Without 3D InfoFrame information
1920 x 1080i @ 50Hz
1920 x1080i @ 60Hz
1280 x 720P @50Hz
1280 x 720P @60Hz
Side-by-Side(Half) SBS mode is on
1920 x 1080i @ 50Hz
1920 x1080i @ 60Hz
1280 x 720P @50Hz
1280 x 720P @60Hz
Top-and-Bottom TAB mode is on
480i HQFS (3D format is Frame sequential)
If 3D input is 1080p@24hz, the DMD should replay with integral multiple with 3D mode.
1080i@25hz and 720p @ 50hz will run in 100 Hz. Other 3D timing will run in 120 Hz.
1080P @ 24hz will run 144Hz (XGA, WXGA, 1080p) / 96Hz (WUXGA).
