36
ALARMS
Audible and Visual
Line Failure, Battery Low, Transfer to Bypass,
System Fault Conditions
PHYSICAL
Dimensions
(HxWxD)mm
Power module
440x88x680
440x132x680
440x220x720
With batteries
440x176x680
x
Input/Output Connection
Hardwire
External Battery Connection
Plug-in & Play
Net Weight
(Kgs)
Power module
25
(1Φ) 26Kg
(3Φ) 28Kg
36
With battery
53
x
Heat Dissipation
< 450 W
< 600 W
<1350 W
Leakage Current
< 3mA at Full Load
MARKS
CE
* (160~176Vac for 1-phase input model or 277~305Vac for 3-phase input model at <50% load)
***These cards are not suitable to use simultaneously.
MODEL TOWER
15K/20K
INPUT
Voltage Window
277–485 VAC (3Φ)
Frequency
45-65 Hz
Phase/Wire
3Ph + Neutral + Ground
Power Factor
Up to 0.95 at 100% Linear Load
OUTPUT
Voltage Window
220/230/240 VAC
Voltage Adjustment
±0%, ±1%, ±2%, ±3%
Voltage Regulation
±2%
Capacity
13.5/18KW
Rated Power Factor
0.9 Lagging
Wave Form
Sine Wave, THD<3% (no load to full load)
Frequency Stability
±0.2% (Free Running)
Frequency Regulation
±1Hz, ±3Hz
Transfer Time
0 ms
Crest Factor
3:1 acceptable
Efficiency (AC to AC, Normal)
Up to 91%
Efficiency (AC to AC, ECO)
Up to 95%
DC Start
Yes
BATTERY
Type
Sealed Lead Acid Maintenance Free
