37
Quantity
20 pcs
Voltage
240 VDC
Recharge Time
6 hours to 90%
DISPLAY
Status On LED + LCD
Line Mode, Backup Mode, ECO Mode, Bypass
Supply, Battery Low, Battery Bad/Disconnect,
Overload, Transferring with interruption, UPS
Fault
Readings on LCD
Input Voltage, Input Frequency, Output Voltage,
Output Frequency, Load Percentage, Battery
Voltage, Inner Temperature
Self-Diagnostics
Upon Power-on, Front Panel Setting & Software
Control, 24-hour routine checking
ALARMS
Audible and Visual
Line Failure, Battery Low, Transfer to Bypass,
System Fault Conditions
PHYSICAL
Dimensions WxDxH (mm)
290x650x770
Input/Output Connection
Hard-wired
External Battery Connection
Plug-in & Play
Net Weight (kg)
62
Heat Dissipation
<1350 W
Leakage Current
< 3 mA at Full Load
MARKS
CE
* (190-277 VAC for 3-phase input model at 0~50% load
277-304 VAC for 3-phase input model at 50%>load<75%
304-485 VAC for 3-phase input model at 75%>load<100%)
