trapulsPac - User Guide
Chapter 2 – Commissioning
2.6 - OSCILLOSCOPE
The oscilloscope can be launched in the Gem Drive Studio software or in stand-alone mode.
This oscilloscope allows displaying any drive signal by using the Index / Sub-index identification.
Four different channels are available to display signals. Multi-axis channel operation can be selected.
See Gem Drive Studio Quick Start manual for more details.
2.7 - DIALOG TERMINAL
The dialog terminal can be launched in the Gem Drive Studio software or in stand-alone mode.
This terminal allows:
- Reading a parameter value on a selected axis (continuous value monitoring can also be performed).
- Writing a parameter value on a selected axis.
It is possible to read and/or write parameters on 4 different axes at the same time.
See GemDriveStudio Quick Start manual for more details.
