trapulsPac - User Guide
Chapter 3 – Reference
Sub Index 2
Description Motor temperature warning threshold
Data Type Unsigned32
Access rw
PDO Mapping No
Unit Ω (ohm)
Default value 2400
This parameter defines the threshold of the equivalent resistor corresponding to the temperature at which a
warning will be notified.
Sub Index 3
Description Motor temperature error threshold
Data Type Unsigned32
Access rw
PDO Mapping No
Unit Ω (ohm)
Default value 2400
This parameter defines the threshold of the equivalent resistor corresponding to the temperature at which an error
will be triggered.
Inde
x
0x3323
Name Motor temperature probe monitoring
Object Code VAR
Data Type Unsigned32
Object Class all
Access ro
Unit Ω (ohm)
PDO Mapping No
The returned value gives an image of the equivalent resistance (in Ω).
3.2.2.6 - IGBT temperature
IGBT module temperature value
Index 0x3328
Name IGBT module temperature information
Object Code VAR
Data Type Integer 16
Object Class all
Access ro
PDO Mapping Yes
Unit °C
Remark Only valid for the 400 V range
