Infrasonic Amon - Hardware Specifications; Analog Audio Specifications

7. Hardware Specification
[ANALOG AUDIO]
SAMPLE RATE SUPPORTS 44.1, 48, 88.2, 96 kHz
ANALOG LINE INPUT
Input type Line input 1,2
Connector type 1/4" TS phone jack
Peak level 0dBFS @ +6dBV
Impedance About 10KΩ
MIC INPUT
Input type MIC input for dynamic microphone
Connector type 1/4" TRS phone jack
Preamp gain +60dB (TBD)
Peak level 0dBFS @ 20Mv
Impedance About 1KΩ
Hi-Z INPUT
Input type High impedance input for instrument
Connector type 1/4" TS phone jack
Peak level 0dBFS @ +0dBV
Impedance About 1MΩ
ANALOG OUTPUT
Output type Line output 12
Connector type 1/4" TS phone jack
Peak level +0dBV @ 0dBFS
Attenuation -64dB ~ +0dB(0.5dB step size)
Impedance Less than 30Ω
HEADPHONE OUTPUT
Output type Headphone amplifier
Connector type 1/4" TRS(stereo) phone jack
Load impedance range 32-300Ω (for the best performance)
Output power 60mW @ THD<0.1% ; Vpp = 3.5V
AMON User’s Manual
15
