Wedge Diagnostic Display Codes
If the fault indicator lamp is illuminated, refer to the Alert/Shutdown list below.
If the fault indicator lamp is illuminated, refer to the Engine diagnostic list below.
ALERT/SHUTDOWN CONDITIONS Version: 1.40
Alert Shutdown
Condition Code Light (Blinks) Code Light (Steady) Delay
(sec.)
Engine Speed <900 RPM 1 CPRSR Malf. 30
Engine Speed >2500 RPM 2 CPRSR Malf. 30
Engine Crank Time Exceeded 3 CPRSR Malf. 0
Intake Manifold Temperature > 180
deg. F
6 CPRSR Malf.
Engine Not Responding To Throttle
Command
10 CPRSR Malf.
Engine Shut Itself Down: reason
unknown
29 CPRSR Malf.
Disch. Temp (RT2)
Sensor Fault
32 CPRSR Malf. 10
Sep. Tank Pressure (PT1)
Sensor Fault
33 CPRSR Malf.
Separator Tank Temp.> 247 deg.F) 50 CPRSR Malf. 3
Machine ID Not Valid 51 CPRSR Malf. 0
Sep. Tank Temp. (RT1) Sensor Fault 53 CPRSR Malf. 10
Reg. System Pressure (PT2) Sensor
Fault
54 CPRSR Malf.
Serial Comm. Problem 70 CPRSR Malf.
CAN Bus Problem 71 CPRSR Malf.
To Next Page
