1 6 IDS404 INSTALLER MANUAL NO. 700-277-02A ISSUED SEPT 2004 VER 1.02
IDS404 INSTALLER MANUAL
Table 3: Binary Representation
eulaV
0 1 2 3 4 5 6 7 8 9 01 11 21 31 41 51
2(1enoZ
0
)1=
#
"
#
"
#
"
#
"
#
"
#
"
#
"
#
"
2(2enoZ
1
)2=
##
""
##
""
##
""
##
""
2(3enoZ
2
)4=
####
""""
####
""""
2(4enoZ
3
)8=
########
""""""""
#
dehsiugnitxE
"
detanimullI
15.3 Programming the Panel
! For all programming procedures, the [
!!
!!
!] (star) key functions as
the enter key and the [#] (hash) key functions as a clear key to
clear incorrect or unintended entries, as a back space and to exit
the programming mode.
! If an error has been made i.e. an attempt is made to enter an
illegal value or an incorrect series of keystrokes, the keypad will
beep three times to indicate the error. The panel will automatically
discard the invalid entry allowing the correct entry to be made
without manually clearing the incorrect entry.
Procedure
1. Ensure that the panel is not armed.
2. Press the [#] key (this will clear any previous or accidental
entries) followed by the 4 digit [INSTALLER CODE] (the default
code is 9999).
3. If the correct code has been entered the green READY indicator
will begin flashing.
4. Press the [
!!
!!
!] key.
5. Enter the [LOCATION NUMBER] of the program location that you
wish to change.
6. Press the [
!!
!!
!] key. The READY indicator will continue flashing and
the AWAY indicator will illuminate.
7. The zone LED’s will now display the content of the selected
program location in binary format (ref. Table 3).
8. If you wish to change the content of the location, enter the [NEW
VALUE
] followed by the [
!!
!!
!] key. If you do not wish to change the
