IDS404 INSTALLER MANUAL NO. 700-277-02A ISSUED SEPT 2004 VER 1.02 37
IDS404 INSTALLER MANUAL
Table 9: Alarm reporting codes
eulaV noitpircseD sAdetropeR
01yralgruB0311
1retemireP1311
2roiretnI2311
3)efaS(ruoH423311
4tixE/yrtnE4311
5thgiN/yaD5311
6roodtuO6311
7repmaT7311
8mralAraeN8311
EXAMPLE
Assuming for a given installation it is required to differentiate between
entry/exit, interior and general burglary zones, and assuming that zone
1 is a front door (entry/exit zone), zone 2 is an interior PIR (interior
zone) and zone 3 is a general burglary zone.
Program the following locations
1. Location 106 (Zone 1) = 4 (Code 1134 = ENTRY/EXIT)
2. Location 108 (Zone 2) = 2 (Code 1132 = INTERIOR)
3. Location 110 (Zone 3) = 10 (Code 1130 = BURGLARY)
NOTES ON DOMESTIC REPORTING:
Domestic reporting will dial both phone numbers as programmed into
locations 68-83 and 84-99. The data to be reported will be transmitted
3 times immediately after the phone number is dialled. This format
provides for a simple form of easily identifiable remote alarm which
may be reported to an office, mobile phone etc.
When using Domestic Reporting the number will be dialled and the
data will be transmitted the number of times as programmed into the
number of dial attempts (location 171).
NOTES ON PROGRAMMING TELEPHONE NUMBERS:
! To dial a “0” program a [10] into the location.
! To dial a “!” program an [11] into the location.
