40 Programming from the panel
Installation and programming manual
Chapter 8
Programming from the panel
The control panel and its points and zones can be programmed and configured via the control panel or by
means of the SmartLeague software programme. For a brief description of the software application and the
programming process, refer to Chapter 15 - SmartLeague software or, for a more complete description,
refer to the SmartLeague user's guide.
Access to programming is allowed only after the programming jumper has been inserted:
1. Remove the frontplate.
2. Insert the programming jumper (refer to paragraph 4.1 - [Q]).
3. The display will show the relevant message.
4. The panel switches Off: no faults or alarms will be signaled.
If this message appears, the programming phase has been blocked via
PC. If this occurs, only maintenance functions can be accessed.
Note: To unblock the programming phase, start the SmartLeague application on the PC and type in the code
previously used to block it. This feature protects the system from being accessed by persons other than
qualified technicians authorized by the Installer company.
Menu options
Press Ok to access the zone screen.
‘
’ indicates that there is further information after the last line.
Press Esc to step back to the previous screen.
Editable alphanumeric field
Use keys SandT to move along the string.
Press and hold Ok to scroll the alphanumeric characters.
Press Esc to confirm the data entry, exit and step back to the previous
screen.
Editable numeric field
Press and hold Ok to scroll the values the two-digit counters (e.g.: 0
to 99 and “--”, which means non-specified).
Use key SorT to move to the next programming field.
Press Esc to confirm the data entry, exit and step back to the previous
screen.
Variable field
Use key SorT to scroll the list.
Press Ok to toggle the parameter in the programming field (e.g.: YES
to NO).
Press Esc to confirm the data entry, exit and step back to the previous
screen.
Control panel
IN PROGRAMMING
ver. 2.00
07/07/11 00:00
Control panel
IN MAINTENANCE
ver. 2.00
07/07/11 00:00
J
001<Zone Descr.>
002<Zone Descr.>
003<Zone Descr.>
004<Zone Descr.>
l
Modify descr.
j l : move OK: mod.
<Zone 001>
J Delay mains fail
-- hour -- min.
Delay dialler
-- min -- sec
Alarm: YES
Pre-alarm: YES
FAULT: YES
Enabled: NO
