Inovance IS650P Series - Group H12: Multi-Speed Function Parameters

6 Parameter Table
6
- 86 -
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H11-90
Acceleration/Deceleration time of
16th displacement
0 to 65535 ms (s) 10
Im Ru
P
H11-91 Waiting time after 16th displacement 0 to 10000 ms (s) 10
Im Ru
P
Group H12: Multi-Speed Function Parameters
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H12-00 Multi-speed running mode
0: Stop after running single cycle
1: Cyclic running
2: DI switchover
- 1
Im St
S
H12-01
Number of speed reference
prole
1 to 16 - 16
Im St
S
H12-02 Time unit 0: sec; 1: min - 0
Im St
S
H12-03 Acceleration time 1 0 to 65535 ms 10
Im St
S
H12-04 Deceleration time 1 0 to 65535 ms 10
Im St
S
H12-05 Acceleration time 2 0 to 65535 ms 50
Im St
S
H12-06 Deceleration time 2 0 to 65535 ms 50
Im St
S
H12-07 Acceleration time 3 0 to 65535 ms 100
Im St
S
H12-08 Deceleration time 3 0 to 65535 ms 100
Im St
S
H12-09 Acceleration time 4 0 to 65535 ms 150
Im St
S
H12-10 Deceleration time 4 0 to 65535 ms 150
Im St
S
H12-20 1st speed reference -6000 to 6000 RPM 0
Im St
S
H12-21
Running time of 1st speed
reference
0 to 6553.5
s
(min)
5.0
Im St
S
H12-22
Acceleration/deceleration time
of 1st speed reference
0: No acceleration/deceleration time
1: Acceleration/Deceleration time 1
2: Acceleration/Deceleration time 2
3: Acceleration/Deceleration time 3
4: Acceleration/Deceleration time 4
- 0
Im St
S
H12-23 2nd speed reference -6000 to 6000 RPM 100
Im St
S
H12-24
Running time of 2nd speed
reference
0 to 6553.5
s
(min)
5.0
Im St
S
H12-25
Acceleration/deceleration time
of 2nd speed reference
0: No acceleration/deceleration time
1: Acceleration/Deceleration time 1
2: Acceleration/Deceleration time 2
3: Acceleration/Deceleration time 3
4: Acceleration/Deceleration time 4
- 0
Im St
S
H12-26 3rd speed reference -6000 to 6000 RPM 300
Im St
S
H12-27
Running time of 3rd speed
reference
0 to 6553.5
s
(min)
5.0
Im St
S
H12-28
Acceleration/deceleration time
of 3rd speed reference
0: No acceleration/deceleration time
1: Acceleration/Deceleration time 1
2: Acceleration/Deceleration time 2
3: Acceleration/Deceleration time 3
4: Acceleration/Deceleration time 4
- 0
Im St
S
H12-29 4th speed reference -6000 to 6000 RPM 500
Im St
S
