Parameter Description MD280/MD280N User Manual
- 174 -
0˖The stop function of STOP/RES key is valid only in the keyboard control
mode: Only when the command source (F0-00) is set to “Operation Panel
Control Channel" will the stop function of STOP be valid and the terminal
and serial communication control mode are invalid.
1: The stop function of STOP/RES key is valid in any control mode: The
stop function of STOP is valid when the command source (F0-00) is in
“Operation Panel Control Channel", “Terminal Command Channel”, or
“Serial Port Communication Control Channel”.
Remark: The fault reset function of the STOP/RES key is valid in any
control mode.
software version
No.
Factory default value —
F7-17
Setup range software version No.
Group F8 MS Speed Function and Simple PLC Function
Simple PLC function means that he inverter has a built-in programmable
controller (PLC) to perform automatic control on the MS frequency logic.
The running time, running direction and running frequency can be set to
comply with the process requirements.
This inverter can implement 8-segment speed variable control and has two
types of acceleration/deceleration time for selection.
When the setup PLC completes one cycle, it can output PLC circulation
end signal via the multifunctional output terminal DO or multifunctional
relay (RELAY). Refer to the description of “PLC Circulation End” of the
output terminal in Group F3 for details.
When the frequency source selection (F0-01) is set to MS speed running
mode, it only needs to set the function codes of F8-00 to F8-08 to
determine its characteristics.
MS speed 0
reference mode
Factory default
value
0
0
Function code
F8-01 reference
1 AI1
2 AI2
3 PULSE
F8-00
Setup
range
4 PID
