Function Code Table
MD380 User Manual
- 130 -
Function
Code
Parameter Name
Setting Range
Default Property
A7-01
Selection of control mode of
the output terminals on the
control board
Unit's digit: FMR (FM used as
digital output)
0 ★
0: Controlled by the AC drive
1: Controlled by the user
programmable card
Ten's digit: relay (T/A-T/B-T/C)
Same as unit's digit
Hundred's digit: DO1
Same as unit's digit
Thousand's digit FMR (FM used
as pulse output)
Same as unit's digit
Ten thousand's digit: AO1
Same as unit's digit
A7-02
AI/AO function selection of
the user programmable card
0: AI3 (voltage input), AO2
(voltage output)
1: AI3 (voltage input), AO2
(current output)
2: AI3 (current input), AO2
(voltage output)
3: AI3 (current input), AO2
(current output)
4: AI3 (PTC input), AO2 (voltage
output)
5: AI3 (PTC input), AO2 (current
output)
6: AI3 (PTC100 input), AO2
(voltage output)
7: AI3 (PTC100 input), AO2
(current output)
0 ★
A7-03 FMP output
0.0%–100.0%
0.0% ☆
A7-04 AO1 output
0.0%–100.0%
0.0% ☆
A7-05 Digital output
Binary setting
Unit's digit: FMR
Ten's digit: Relay1
Hundred's digit: DO
1 ☆
A7-06
Frequency setting through
the user programmable card
-100.00% to 100.00%
0.0% ☆
A7-07
Torque setting through the
user programmable card
-200.00% to 200.00%
0.0% ☆
