MD380 User Manual Function Code Table
- 129 -
Function
Code
Parameter Name
Setting Range
Default Property
A6-07
Corresponding setting of AI
curve 4 maximum input
-100.0%–100.0%
100.0% ☆
A6-08 AI curve 5 minimum input
-10.00 V to A6-10
0.00 V ☆
A6-09
Corresponding setting of AI
curve 5 minimum input
-100.0%–100.0%
0.0% ☆
A6-10 AI curve 5 inexion 1 input
A6-08 to A6-12
3.00 V ☆
A6-11
Corresponding setting of AI
curve 5 inexion 1 input
-100.0%–100.0%
30.0% ☆
A6-12 AI curve 5 inexion 1 input
A6-10 to A6-14
6.00 V ☆
A6-13
Corresponding setting of AI
curve 5 inexion 1 input
-100.0%–100.0%
60.0% ☆
A6-14 AI curve 5 maximum input
A6-14 to 10.00 V
10.00 V ☆
A6-15
Corresponding setting of AI
curve 5 maximum input
-100.0%–100.0%
100.0% ☆
A6-16
Jump point of AI1 input
corresponding setting
-100.0%–100.0%
0.0% ☆
A6-17
Jump amplitude of AI1 input
corresponding setting
0.0%–100.0%
0.5% ☆
A6-18
Jump point of AI2 input
corresponding setting
-100.0%–100.0%
0.0% ☆
A6-19
Jump amplitude of AI2 input
corresponding setting
0.0%–100.0%
0.5% ☆
A6-20
Jump point of AI3 input
corresponding setting
-100.0%–100.0%
0.0% ☆
A6-21
Jump amplitude of AI3 input
corresponding setting
0.0%–100.0%
0.5% ☆
Group A7: User Programmable Function
A7-00
User programmable function
selection
0: Disabled
1: Enabled
0 ★
