Description of Function Codes
MD380 User Manual
- 170 -
Function Code Parameter Name Setting Range Default
F4-28 Pulse minimum input 0.00 kHz to F4-30 0.00 kHz
F4-29
Corresponding setting of
pulse minimum input
-100.00%–100.0% 0.0%
F4-30 Pulse maximum input F4-28 to 50.00 kHz 50.00 kHz
F4-31
Corresponding setting of
pulse maximum input
-100.00%–100.0% 100.0%
F4-32 Pulse lter time 0.00–10.00s 0.10s
These parameters are used to set the relationship between DI5 pulse input and
corresponding settings. The pulses can only be input by DI5. The method of setting this
function is similar to that of setting AI1 function.
Function Code Parameter Name Setting Range Default
F4-33 AI curve selection
Unit's digit (AI1 curve selection)
321
Curve 1 (2 points, see F4-13 to F4-16)
Curve 2 (2 points, see F4-18 to F4-21)
Curve 3 (2 points, see F4-23 to F4-26)
Curve 4 (4 points, see A6-00 to A6-07)
Curve 5 (4 points, see A6-08 to A6-15)
Ten's digit (AI2 curve selection)
Curve 1 to curve 5 (same as AI1)
Hundred's digit (AI3 curve selection)
Curve 1 to curve 5 (same as AI1)
The unit's digit, ten's digit and hundred's digit of this parameter are respectively used to
select the corresponding curve of AI1, AI2 and AI3. Any of the ve curves can be selected
for AI1, AI2 and AI3.
Curve 1, curve 2 and curve 3 are all 2-point curves, set in group F4. Curve 4 and curve 5
are both 4-point curves, set in group A6.
The MD380 provides two AI terminals as standard. AI3 is provided by an optional extension
card.
Function Code Parameter Name Setting Range Default
F4-34
Setting for AI less
than minimum input
Unit's digit (Setting for AI1 less than
minimum input)
000
0: Minimum value
1: 0.0%
Ten's digit (Setting for AI2 less than
minimum input)
0, 1 (same as AI1)
Hundred's digit (Setting for AI3 less
than minimum input)
0, 1 (same as AI1)
