MD380 User Manual Desc
ription of Function Codes
- 229 -
Function Code Parameter Name Setting Range Default
A2-01 Rated motor power
0.1–1000.0 kW
Model
dependent
A2-02 Rated motor voltage
1–2000 V
Model
dependent
A2-03 Rated motor current
0.01–655.35 A (AC drive power ≤ 55 kW)
0.1–6553.5 A (AC drive power > 55 kW)
Model
dependent
A2-04
Rated motor
frequency
0.01 Hz to maximum frequency
Model
dependent
A2-05
Rated motor rotational
speed
1–65535 RPM
Model
dependent
A2-06
Stator resistance
(asynchronous motor)
0.001–65.535
Ω
(AC drive power ≤ 55 kW)
0.0001–6.5535
Ω
(AC drive power > 55 kW)
Model
dependent
A2-07
Rotor resistance
(asynchronous motor)
0.001–65.535
Ω
(AC drive power ≤ 55 kW)
0.0001–6.5535
Ω
(AC drive power > 55 kW)
Model
dependent
A2-08
Leakage inductive
reactance
(asynchronous motor)
0.01–655.35 mH (AC drive power ≤ 55 kW)
0.001–65.535 mH (AC drive power > 55
kW)
Model
dependent
A2-09
Mutual inductive
reactance
(asynchronous motor)
0.1–6553.5 mH (AC drive power ≤ 55 kW)
0.01–655.35 mH (AC drive power > 55 kW)
Model
dependent
A2-10
No-load current
(asynchronous motor)
0.01 A to A2-03 (AC drive power ≤ 55 kW)
0.1 A to A2-03 (AC drive power > 55 kW)
Model
dependent
A2-16
Stator resistance
(synchronous motor)
0.001–65.535
Ω
(AC drive power ≤ 55 kW)
0.0001–6.5535
Ω
(AC drive power > 55 kW)
Model
dependent
A2-17
Shaft D inductance
(synchronous motor)
0.01–655.35 mH (AC drive power ≤ 55 kW)
0.001–65.535 mH (AC drive power > 55
kW)
Model
dependent
A2-18
Shaft Q inductance
(synchronous motor)
0.01–655.35 mH (AC drive power ≤ 55 kW)
0.001–65.535 mH (AC drive power > 55
kW)
Model
dependent
A2-20
Back EMF
(synchronous motor)
0.1–6553.5 V
Model
dependent
A2-27
Encoder pulses per
revolution
1–65535
1024
A2-28 Encoder type
0: ABZ incremental encoder
1: UVW incremental encoder
2: Resolver
3: SIN/COS encoder
4: Wire-saving UVW encoder
0
A2-30
A, B phase sequence
of ABZ incremental
encoder
0: Forward
1: Reserve
0
