MD380 User Manual Product Information
- 23 -
Item Specications
RUN Output terminal
Standard:
• 1 high-speed pulse output terminal (open-collector)
that supports 0–100 kHz square wave signal output
• 1 digital output (DO) terminal
• 1 relay output terminal
• 1 analog output (AO) terminal that supports 0–20
mA current output or 0–10 V voltage output
Expanding capacity:
• 1 DO terminal
• 1 relay output terminal
• 1 AO terminal that supports 0–20 mA current output
or 0–10 V voltage output
Display and
operation on
the operation
panel
LED display It displays the parameters.
Parameter clone
Parameters can be cloned quickly via the optional
LCD operation panel.
Key locking and function
selection
It can lock the keys partially or completely and dene
the function range of some keys so as to prevent mis-
function.
Protection mode
Motor short-circuit detection at power-on, input/
output phase loss protection, overcurrent protection,
overvoltage protection, undervoltage protection,
overheat protection and overload protection
Optional parts
LCD operation panel, braking unit, I/O extension
card 1, I/O extension card 2, user programmable
card, RS485 communication card, PROFIBUS-DP
communication card, CANlink communication card,
CANopen communication card, differential input PG
card, UVW differential input PG card, resolver PG card
and OC input PG card
Environment
Installation location
Indoor, free from direct sunlight, dust, corrosive gas,
combustible gas, oil smoke, vapour, drip or salt.
Altitude Lower than 1000 m
Ambient temperature
-10°C to +40°C
Humidity Less than 95%RH, without condensing
Vibration Less than 5.9 m/s
2
(0.6 g)
Storage temperature -
20°C to +60°C
IP level IP20
Pollution degree PD2
Power distribution
system
TN, TT
