MD380 User Manual Desc
ription of Function Codes
- 241 -
Function Code Parameter Name Display Range
U0-03 Output voltage 0–1140 V
It displays the AC drive's output voltage in the running state.
Function Code Parameter Name Display Range
U0-04 Output current
0.00–655.35 A (AC drive power ≤ 55 kW)
0.0–6553.5 A (AC drive power > 55 kW)
It displays the AC drive's output current in the running state.
Function Code Name Display Range
U0-05 Output power 0–32767
It displays the AC drive's output power in the running state.
Function Code Parameter Name Display Range
U0-06 Output torque -200.0%–200.0%
It displays the AC drive's output torque in the running state.
Function Code Parameter Name Display Range
U0-07 DI state 0–32767
It displays the current state of DI terminals. After the value is converted into a binary number,
each bit corresponds to a DI. "1" indicates high level signal, and "0" indicates low level signal.
The corresponding relationship between bits and DIs is described in the following table.
Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6 Bit7 Bit8 Bit9
DI1 DI2 DI3 DI4 DI5 DI6 DI7 DI8 DI9 DI10
Bit10 Bit11 Bit12 Bit13 Bit10 Bit11 Bit12 Bit13 Bit14 Bit15
VDI1 VDI2 VDI3 VDI4 VDI1 VDI2 VDI3 VDI4 VDI5
Function Code Parameter Name Display Range
U0-08 DO state 0–1023
It indicates the current state of DO terminals. After the value is converted into a binary
number, each bit corresponds to a DO. "1" indicates high level signal, and "0" indicates
low level signal. The corresponding relationship between bits and DOs is described in the
following table.
Table 6-15 Corresponding relationship between bits and DOs
Bit0 Bit1 Bit2 Bit3 Bit4 Bit5
DO3 Relay 1 Relay 2 DO1 DO2 VDO1
Bit6 Bit7 Bit8 Bit9 Bit10 Bit11
VDO2 VDO3 VDO4 VDO5
