Description of Function Codes
MD380 User Manual
- 242 -
Function Code Parameter Name Display Range
U0-10 AI2 voltage (V)/current (mA)
0.00–10.57 V
0.00–20.00 mA
When F4-40 is set to 0, AI2 samplin g data is displayed in the unit of V.
When F4-40 is set to 1, AI2 sampling data is displayed in the unit of mA.
Function Code Parameter Name Display Range
U0-14 Load speed 0–65535
For more details, see the description of F7-12.
Function Code Parameter Name Display Range
U0-15 PID setting 0–65535
U0-16 PID feedback 0–65535
They display the PID setting value and PID feedback value.
• PID setting = PID setting (percentage) x FA-04
• PID feedback = PID feedback (percentage) x FA-04
Function Code Parameter Name Display Range
U0-18 Input pulse frequency 0.00–100.00 kHz
It displays the high-speed pulse sampled frequency of DI5, in minimum unit of 0.01 kHz.
Function Code Parameter Name Display Range
U0-19 Feedback speed
-320.00–320.00 Hz
-3200.0–3200.0 Hz
It displays the actual output frequency of the AC drive.
• If F0-22 (Frequency reference resolution) is set to 1, the display range is -3200.00–
3200.00 Hz.
• If F0-22 (Frequency reference resolution) is set to 2, the display range is -320.00Hz–
320.00 Hz.
Function Code Parameter Name Display Range
U0-20 Remaining running time 0.0–6500.0 min
It displays the remaining running time when the timing operation is enabled. For details on
timing operation, refer to F8-42 to F8-44.
Function Code Parameter Name Display Range
U0-21 AI1 voltage before correction 0.00–10.57 V
U0-22 AI2 voltage (V)/ current (mA) before correction
0.00–10.57 V
0.00–20.00 mA
U0-23 AI3 voltage before correction -10.57–10.57 V
