Selection and Dimensions MD380 User Manual
- 264 -
Model
Mounting
Hole
(mm)
Overall Dimensions
(mm)
Mounting
Hole
Diameter
(mm)
Weight
(kg)
A B H H1 W D
Three-phase 220 V
MD380-2T0.4GB
113 172 186 / 125 164 ø5.0 1.1
MD380-2T0.75GB
MD380-2T1.5GB
MD380-2T2.2GB
148 236 248 / 160 183 ø5.0 2.5
MD380-2T3.7GB
MD380-2T5.5GB
190 305 322 / 208 192 ø6 6.5
MD380-2T7.5GB
MD380-2T11G
235 447 432 463 285 228 ø6.5 20
MD380-2T15G
MD380-2T18.5G
260 580 549 600 385 265 ø10 32MD380-2T22G
MD380-2T30G
MD380-2T37G
343 678 660 700 473 307 ø10 47
MD380-2T45G
MD380-2T55G
449 903 880 930 579 380 ø10 90
MD380-2T75G
Three-phase 380 V
MD380T0.7GB
113 172 186 / 125 164 ø5.0 1.1MD380T1.5GB
MD380T2.2GB
MD380T3.7GB
148 236 248 / 160 183 ø5.0 2.5
MD380T5.5GB
MD380T7.5GB
190 305 322 / 208 192 ø6 6.5MD380T11GB
MD380T15GB
MD380T18.5G
235 447 432 463 285 228 ø6.5 20MD380T22G
MD380T30G
MD380T37G
260 580 549 600 385 265 ø10 32MD380T45G
MD380T55G
