MD380 User Manual Selection and Dimensions
- 265 -
Model
Mounting
Hole
(mm)
Overall Dimensions
(mm)
Mounting
Hole
Diameter
(mm)
Weight
(kg)
A B H H1 W D
MD380T75G
MD380T90P
343 678 660 700 473 307 ø10 47
MD380T90G
MD380T110G
449 903 880 930 579 380 ø10 90MD380T132G
MD380T160G
MD380T110GH
320 1166 1090 1192 440 310 ø10 90MD380T132GH
MD380T160GH
MD380T200G
420 1030 983 1060 650 377 ø12 130
MD380T220G
MD380T250G
MD380T280G
MD380T315G
520 1300 1203 1358 800 400 ø16 200MD380T355G
MD380T400G
Three-phase 480 V
MD380-5T0.7GB
113 172 186 / 125 164 ø5.0 1.1MD380-5T1.5GB
MD380-5T2.2GB
MD380-5T3.7GB
148 236 248 / 160 183 ø5.0 2.5
MD380-5T5.5GB
MD380-5T7.5GB
190 305 322 / 208 192 ø6 6.5MD380-5T11GB
MD380-5T15GB
MD380-5T18.5G
235 447 432 463 285 228 ø6.5 20MD380-5T22G
MD380-5T30G
MD380-5T37G
260 580 549 600 385 265 ø10 32MD380T45G
MD380T55G
