Selection and Dimensions MD380 User Manual
- 266 -
Model
Mounting
Hole
(mm)
Overall Dimensions
(mm)
Mounting
Hole
Diameter
(mm)
Weight
(kg)
A B H H1 W D
MD380-5T75G
343 678 660 700 473 307 ø10 47
MD380-5T90G
MD380-5T110G
449 903 880 930 579 380 ø10 90MD380-5T132G
MD380-5T160G
MD380-5T200G
420 1030 983 1060 650 377 ø12 130
MD380-5T220G
MD380-5T250G
MD380-5T280G
MD380-5T315G
520 1300 1203 1358 800 400 ø16 200MD380-5T355G
MD380-5T400G
Three-phase 690 V
MD380-7T55G
250 570 557 600 400 330 ø10 47
MD380-7T75G
MD380-7T90G
MD380-7T110G
MD380-7T132G
MD380-7T160GH
320 1166 1090 1192 440 310 ø10 90
MD380-7T200GH
MD380-7T220GH
MD380-7T250GH
MD380-7T280G
420 1030 983 1060 650 377 ø12 130MD380-7T315G
MD380-7T355G
MD380-7T400G
520 1300 1203 1358 800 400 ø16 200MD380-7T450G
MD380-7T500G
