Selection and Dimensions MD380 User Manual
- 282 -
Model
Recommended
Power
Recommended
Resistance
Braking Unit Remark
MD380-2T55G 5.5 kW x 2 ≥ 4 Ω x 2 External MDBUN-60-S x 2
MD380-2T75G 16 kW ≥ 1.2 Ω External MDBUN-90-S x 2
Three-phase 380 V
MD380T0.7GB 150 W ≥ 300 Ω
Built-in
(standard)
No special description
MD380T1.5GB 150 W ≥ 220 Ω
MD380T2.2GB 250 W ≥ 200 Ω
MD380T3.7GB 300 W ≥ 130 Ω
MD380T5.5GB 400 W ≥ 90 Ω
MD380T7.5GB 500 W ≥ 65 Ω
MD380T11GB 800 W ≥ 43 Ω
MD380T15GB 1000 W ≥ 32 Ω
MD380T18.5G 1300 W ≥ 25 Ω
Built-in
(optional)
Add "B" to the model if a
braking unit is needed.
MD380T22G 1500 W ≥ 22 Ω
MD380T30G 2500 W ≥ 16 Ω
MD380T37G 3.7 kW ≥ 16.0 Ω External MDBUN-45-T
MD380T45G 4.5 kW ≥ 16 Ω External MDBUN-60-T
MD380T55G 5.5 kW ≥ 8 Ω External MDBUN-60-T
MD380T75G 7.5 kW ≥ 8 Ω External MDBUN-90-T
MD380T90G 4.5 kW x 2 ≥ 8 Ω x 2 External MDBUN-60-T x 2
MD380T110G 5.5 kW x 2 ≥ 8 Ω x 2 External MDBUN-60-T x 2
MD380T132G 6.5 kW x 2 ≥ 8 Ω x 2 External MDBUN-90-T x 2
MD380T160G 16 kW ≥ 2.5 Ω External MDBUN-90-T x 2
MD380T200G 20 kW ≥ 2.5 Ω External MDBU-200-B
MD380T220G 22 kW ≥ 2.5 Ω External MDBU-200-B
MD380T250G 12.5 kW x 2 ≥ 2.5 Ω x 2 External MDBU-200-B x 2
MD380T280G 14 kW x 2 ≥ 2.5 Ω x 2 External MDBU-200-B x 2
MD380T315G 16 kW x 2 ≥ 2.5 Ω x 2 External MDBU-200-B x 2
MD380T355G 17 kW x 2 ≥ 2.5 Ω x 2 External MDBU-200-B x 2
MD380T400G 14 kW x 3 ≥ 2.5 Ω x 3 External MDBU-200-B x 3
Three-phase 480 V
MD380-5T0.7GB 150 W ≥ 300 Ω
Built-in
(standard)
No special description
MD380-5T1.5GB 150 W ≥ 220 Ω
MD380-5T2.2GB 250 W ≥ 200 Ω
MD380-5T3.7GB 300 W ≥ 130 Ω
MD380-5T5.5GB 400 W ≥ 90 Ω
MD380-5T7.5GB 500 W ≥ 65 Ω
MD380-5T11GB 800 W ≥ 43 Ω
MD380-5T15GB 1000 W ≥ 32 Ω
MD380-5T18.5G 1300 W ≥ 25 Ω
Built-in
(optional)
Add "B" to the model if a
braking unit is needed.
MD380-5T22G 1500 W ≥ 22 Ω
MD380-5T30G 2500 W ≥ 16 Ω
