MD380 User Manual Selection and Dimensions
- 283 -
Model
Recommended
Power
Recommended
Resistance
Braking Unit Remark
MD380-5T37G 3.7 kW ≥ 16.0 Ω External MDBUN-45-5T
MD380-5T45G 4.5 kW ≥ 16 Ω External MDBUN-45-5T
MD380-5T55G 5.5 kW ≥ 8 Ω External MDBUN-60-5T
MD380-5T75G 7.5 kW ≥ 8 Ω External MDBUN-90-5T
MD380-5T90G 4.5 kW x 2 ≥ 8 Ω x 2 External MDBUN-90-5T
MD380-5T110G 5.5 kW x 2 ≥ 8 Ω x 2 External MDBUN-60-5T x 2
MD380-5T132G 6.5 kW x 2 ≥ 8 Ω x 2 External MDBUN-90-5T x 2
MD380-5T160G 16 kW ≥ 2.5 Ω External MDBUN-90-5T x 2
MD380-5T200G 20 kW ≥ 2.5 Ω External MDBU-200-D
MD380-5T220G 22 kW ≥ 2.5 Ω External MDBU-200-D
MD380-5T250G 12.5 kW x 2 ≥ 2.5 Ω x 2 External MDBU-200-D x 2
MD380-5T280G 14 kW x 2 ≥ 2.5 Ω x 2 External MDBU-200-D x 2
MD380-5T315G 16 kW x 2 ≥ 2.5 Ω x 2 External MDBU-200-D x 2
MD380-5T355G 17 kW x 2 ≥ 2.5 Ω x 2 External MDBU-200-D x 2
MD380-5T400G 14 kW x 3 ≥ 2.5 Ω x 3 External MDBU-200-D x 3
Note
• " x 2" indicates that two braking units with their respective braking resistor are connected in
parallel.
• " x 3" means the same.
