Mechanical and Electrical Installation MD380 User Manual
- 32 -
2) Embedded installation of the MD380 (plastic housing)
Figure 3-4 External hanging bracket for the MD380
Figure 3-5 Embedded installation of the MD380 (plastic housing)
Install the AC drive on the
front of the control cabinet.
Back panel of
control cabinet
Figure 3-6 Embedded installation effect of the MD380 (plastic housing)
