MD380 User Manual Function Code Table
- 81 -
Function
Code
Parameter Name
Setting Range
Default Property
F0-03
Main frequency source X
selection
5: Pulse setting (DI5)
6: Multi-reference
7: Simple PLC
8: PID
9: Communication setting
0 ★
F0-04
Auxiliary frequency source Y
selection
The same as F0-03 (Main
frequency source X selection)
0 ★
F0-05
Range of auxiliary frequency
Y for X and Y operation
0: Relative to maximum frequency
1: Relative to main frequency X
0 ☆
F0-06
Range of auxiliary frequency
Y for X and Y operation
0%–150%
100% ☆
F0-07 Frequency source selection
Unit's digit (Frequency source
selection)
00 ☆
0: Main frequency source X
1: X and Y operation
(operation relationship determined
by ten's digit)
2: Switchover between X and Y
3: Switchover between X and "X
and Y operation"
4: Switchover between Y and "X
and Y operation"
Ten's digit (X and Y operation
relationship)
0: X+Y
1: X-Y
2: Maximum
3: Minimum
F0-08 Preset frequency
0.00 to maximum frequency (valid
when frequency source is digital
setting)
50.00 Hz ☆
F0-09 Rotation direction
0: Same direction
1: Reverse direction
0 ☆
F0-10 Maximum frequency
50.00–320.00 Hz
50.00 Hz ★
F0-11
Source of frequency upper
limit
0: Set by F0-12
1: AI1
2: AI2
3: AI3
4: Pulse setting (DI5)
5: Communication setting
0 ★
