MD380 User Manual Function Code Table
- 87 -
Function
Code
Parameter Name
Setting Range
Default Property
F3-05
Multi-point V/F frequency 2
(F2)
F3-03 to F3-07
0.00 Hz ★
F3-06
Multi-point V/F voltage 2
(V2)
0.0%–100.0%
0.0% ★
F3-07
Multi-point V/F frequency 3
(F3)
F3-05 to rated motor frequency
(F1-04)
Note: The rated frequencies
of motors 2, 3, and 4 are
respectively set in A2-04, A3-04,
and A4-04.
0.00 Hz ★
F3-08
Multi-point V/F voltage 3
(V3)
0.0%–100.0%
0.0% ★
F3-09 V/F slip compensation gain
0%–200.0%
0.0% ☆
F3-10 V/F over-excitation gain
0–200
64 ☆
F3-11
V/F oscillation suppression
gain
0–100
Model
dependent
☆
F3-13
Voltage source for V/F
separation
0: Digital setting (F3-14)
1: AI1
2: AI2
3: AI3
4: Pulse setting (DI5)
5: Multi-reference
6: Simple PLC
7: PID
8: Communication setting
100.0% corresponds to the rated
motor voltage (F1-02, A4-02, A5-
02, A6-02).
0 ☆
F3-14
Voltage digital setting for V/
F separation
0 V to rated motor voltage
0 V ☆
F3-15
Voltage rise time of V/F
separation
0.0–1000.0s
It indicates the time for the
voltage rising from 0 V to rated
motor voltage.
0.0s ☆
F3-16
Voltage decline time of V/F
separation
0.0–1000.0s
It indicates the time for the
voltage to decline from rated
motor voltage to 0 V.
0.0s ☆
F3-17
Stop mode selection upon
V/F separation
0: Frequency
and voltage
declining to 0 independently
1: Frequency decli
ning after
voltage declines to 0
0 ☆
