Function Code Table
MD380 User Manual
- 88 -
Function
Code
Parameter Name
Setting Range
Default Property
Group F4: Input Terminals
F4-00 DI1 function selection
0: No function
1: Forward RUN (FWD)
2: Reverse RUN (REV)
3: Three-line control
4: Forward JOG (FJOG)
5: Reverse JOG (RJOG)
6: Terminal UP
1 ★
F4-01 DI2 function selection
7: Terminal DOWN
8: Coast to stop
9: Fault reset (RESET)
10: RUN pause
11: Normally open (NO) input of
external fault
12: Multi-reference terminal 1
13: Multi-reference terminal 2
4 ★
F4-02 DI3 function selection
14: Multi-reference terminal 3
15: Multi-reference terminal 4
16: Terminal 1 for acceleration/
deceleration time selection
17: Terminal 2 for acceleration/
deceleration time selection
9 ★
F4-03 DI4 function selection
18: Frequency source switchover
19: UP and DOWN setting clear
(terminal, operation panel)
20: Command source switchover
terminal 1
21: Acceleration/Deceleration
prohibited
22: PID pause
23: PLC status reset
24: Swing pause
25: Counter input
26: Counter reset
12 ★
F4-04 DI5 function selection
27: Length count input
28: Length reset
29: Torque control prohibited
13 ★
