MD380 User Manual Function Code Table
- 93 -
Function
Code
Parameter Name
Setting Range
Default Property
F5-03
Extension card relay function
(P/A-P/B-P/C)
14: Torque limited
15: Ready for RUN
16: AI1 larger than AI2
17: Frequency upper limit reached
18: Frequency lower limit reached
(no output at stop)
19: Undervoltage state output
20: Communication setting
21: Reserved
22: Reserved
23: Zero-speed running 2 (having
output at stop)
24: Accumulative power-on time
reached
25: Frequency level detection
FDT2 output
26: Frequency 1 reached
27: Frequency 2 reached
28: Current 1 reached
29: Current 2 reached
30: Timing reached
31: AI1 input limit exceeded
32: Load becoming 0
33: Reverse running
34: Zero current state
35: IGBT temperature reached
36: Software current limit
exceeded
37: Frequency lower limit reached
(having output at stop)
38: Alarm output
39: Motor overheat warning
40: Current running time reached
41: Fault output (There is no
output if it is the coast to stop
fault and undervoltage occurs.)
0 ☆
F5-04
O1 function selection (open-
collector output terminal)
F5-04
DO1 function selection
(open-collector output
terminal)
1 ☆
F5-05 Extension card DO2 function 4 ☆
